100W 12V Monocrystalline Solar Panel

Description

Technical parameters

Maximum Power(W)                           100W

Optimum Power Voltage(Vmp)        17.8V

Optimum Operating Current(Imp)  5.62A

Open Circuit Voltage(Voc)                 21.8V

Short Circuit Current(Isc)                  6.05A

Mechanical Characteristics

No of Cells                             36

Dimensions                           670 x 1030 x 30mm

Weight                                    30 KGS

Front Glass                            3.2mm-High Transmission, Low Iron,Tempered Glass

Junction box                         IP65 Rated

Temperature and Coefficients

Operating Temperature(°C):                                -40°C ~ + 85°C

Maximum System Voltage:                                   600V(UL)/1000V(IEC)

Temperature Coefficients of Pmax:                     -0.435%

Temperature Coefficients of Voc:                        -0.35%

Temperature Coefficients of Isc:                         0.043%

Nominal Operating Cell Temperature (NOCT): 47+/-2°C

Materials of solar panel

1).Solar Cell——Monocrystalline solar cell 156*52mm

2).Front Glass——-3.2mm, high transmission, low iron, tempered glass

3).EVA——-excellent anti-aging EVA

4).TPT——-TPT hot seal made of flame resistance

5).Frame——anodized aluminum profile

6).Junction Box——-IP65 rated, high quality, with diode protection Superiority: high quality anodized aluminum frame, high efficiency long life, easy installation, strong wind resistance, strong hail resistance.

Features

1. High cell efficiency with quality silicon materials for long term output stability

2. Strictly quality control ensure the stability and reliability, totally 23 QC procedures

3. High transmittance low iron tempered glass with enhanced stiffness and impact resistance

4. Excellent performance in harsh weather

5. Outstanding electrical performance under high temperature and low irradiance

Panel includes MC4 Connectors
