Description
PERFORMANCE | |
Rated Capacity (5hr) | 250 Ah |
Nominal Voltage | 48 V |
Discharge Ending Voltage | 40 V |
Charging Limited Voltage | 58.4 V |
Max. Charging Current | 100.0 A |
Max. Continuous Discharging Current | 350.0 A |
Parallel Connection | Optional (up to 16P). When paralleling Max. charging current = 20A |
Containing Cell | 3.2V LiFePO4 Cell |
Design Life | More than 10 years |
Cycle Life | 6000 cycles @85% DOD (dependant on actual DOD, usage & temp.) |
Discharge Rate | 1C |
Response Time | > 1ms |
MECHANICAL SPECIFICATIONS | |
Dimensions (W*D*H) | -* – * – mm (Single Module) |
Weight | -Kg(Single Module) |
Enclosure | 5U steel enclosure with protection handles |
Communication Ports | RS485 RS232 & SNMP available |
OTHER | |
Operating Temperature | Charging: 0 to +45°C / Discharging: -20 to +60°C |
Storage Temperature | -20 to +60°C |
Humidity | 5% to 95% Relative Humidity (Non-condensing) |
Warranty | 5 years |
Other Features
-Safe
OSN LFP battery modules are a practical and economical battery system based on Lithium-iron-phosphate technology (LFP or LiFePO4).
-scalable
Available in standard 12.8kWh modules, the LFP battery modules can be easily scaled in multiples up to 200kWh in a single installation, making them suitable for a range of applications.
-Efficient
OSN’s LFP battery modules feature a round-trip efficiency of 92%, low self discharge rate of 3+ years, and unlike traditional lead acid battery.
