MC4 Compatible Connector Pairs
Price range: $4.99 through $209.00
MC4 Compatible Connector pairs. Ready to crimp on your wire. These are the best quality connectors available for your solar system. They are UV resistant and certified to the exacting standards of Rhineland of North America (TÜV)
Description
Details :
Protection Class:2
Withstanding Voltage: 1000 V DC
Rated Current: 22(2.5 mm),30A (6 mm2)
Specifications:
Insulation Material: PC/PA, black
Temperature Range: -40 C ~ +90 C
Contact Material: Copper, Sliver plated
Flame Class: UL94-VO or UL94-5VA
Rated Current: 30A
Suitable cable: 2.5mm2,4mm2,6mm2(AWG14,AWG12,AWG10)
Pin dimension: 4.0 mm dia.
Contact resistance: ≤0.2mΩ
Waterproof degree：IP67
Flame class: UL94-VO
Safety Class: Ⅱ
Withdrawal force: ≥50N
Insertion force: ≤50N
Insulation material: PPO + PA
Connecting system: crimping connection
Contact material: copper, tin plated
Temperature range: -40 ℃ ~ +90 ℃
Protection Degree: IP 2X unmated; IP67, mated
Wire Size Range: 2.5mm2, 4mm2, 6mm2[AWG14, AWG12, AWG10]
Insulation Material: PC/PA, black
Contact Material: Copper, Sliver plated
Flame Class: UL94-VO or UL94-5VA
Certification: TUV, CE
Additional information
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Quantity | 1 pair, 5 pairs, 10 pairs, 25 pairs, 100 pairs |
